Perovskite laser engraving machine

Perovskite laser engraving machine

This device is a specialized model designed for laser processing of perovskite solar cells P1/P2/P3/P4. The XY engraving platform adopts high-performance linear motors, linear guide pairs, and high-precision grating rulers for closed-loop control; The optical path structure is simple, easy to maintain, with good processing quality, no residual engraving, no damage to the bottom, good line width consistency, and stable process effect.

Introduction:

This device is a specialized model designed for laser processing of perovskite solar cells P1/P2/P3/P4. The XY engraving platform adopts high-performance linear motors, linear guide pairs, and high-precision grating rulers for closed-loop control; The optical path structure is simple, easy to maintain, with good processing quality, no residual engraving, no damage to the bottom, good line width consistency, and stable process effect.

Product advantages:

Different light sources can be selected according to different process requirements, including 200-500W fiber lasers, 20-30W picosecond (UV, green) lasers, and femtosecond (UV, green) lasers;

The laser optical path system includes a laser, a 45 degree reflector, a beam expander, a diaphragm, DOE optical components, high-speed scanning galvanometer, field lens, customized optical path, and excellent processing effect;

The electric Z-axis focal length adjustment design avoids complex adjustments when processing products of different thicknesses;

Equipped with high-precision visual positioning system and um level rangefinder, * * * positioning, stable efficiency;

Equipped with a visual positioning system to assist laser engraving and improve processing quality;

Equipped with a laser power meter to detect the real-time output power of the laser.

Application fields:

Scratching of Perovskite Solar Cells
